NC ARBORETUM CLASS JUNE 3-4, 2017

by Kathy Goodson

PAINTING BOTANICALS ON SILK

Don't forget to sign up for the two day class at the NC Arboretum near Asheville, NC. There are still a few more spaces. Most supplies are provided. View the class and register for the class here.

Weekend Marbling with a friend in my Studio

by Kathy Goodson

Friday Day 1

The first day was spent marbling. We prepared the Carrageen solution Thursday evening as well as the alum solution for soaking the silk scarf. I have borrowed the directions from Dharma Trading on marbling.

Marbling Basics

Marbling is the process of floating fabric paints on the surface of a thick cellulose solution (called "size"), somewhat like oil on water. The floating paints are swirled into patterns. Then you capture your design by laying a treated piece of fabric or paper down on top of the paint to transfer the swirls to the fabric. It is that easy! When most crafters think of marbling they think of the fancy end papers in old books. But there is so much more you can do with marbling and all you need to get started is a desire to play!

Prep Work

Most of the work in marbling is getting set up, but once you are all set up you can play for hours!


**

Making a frame

**

If you are working with fabric or clothing larger than your available pans, it's easy to build a pan using some 1" x 4" wood. Nail together a frame without top or bottom and just line it with some heavy plastic. You can make the frame any size you need.

*> We made a frame out of PVC plastic pipe and elbows to be larger than the size of silk we dipped. * How much size do I need?

Note: Remember you'll have to change out the size periodically.

**

Preparing the "size"

**

The first thing you need to do is to make the size onto which you are going to float the fabric paints.

Carrageen (Blender type): make 24 hours before it is going to be used.

Use 2 tsp per 4 cups of warm water, slowly add to the water through top hole in blender lid. Blend until it's fully dissolved, make as many batches as you need to fill your tray or frame.

Refrigerate for 24 hours to obtain the best viscosity and to allow trapped air bubbles to rise to the surface.

Before use it needs to be warmed to room temperature.

Methocel: can be made 30 min before use

Use 4 tblsp of Methocel and 1 tblsp of ammonia per gallon of warm water

In a bucket, add ammonia to the water and then slowly add Methocel, stirring constantly with a whisk or large spoon.

Pro-tip: Don’t use the blender or it will foam up and have to sit over night, ask us how we know!

Stir until the Methocel is dissolved and appears clear, let sit for 30 min for bubbles to rise.

How thick the "size" needs to be will vary with the brand of paint being used and the effects you like best.

Pro-Tip: We found doubling the Methocel recipe above kept most paints from sinking and gave us neat spreading patterns with the thinner paints.

Fill your pan or frame with the size, and just before adding the paints, skim off any film that has formed on the surface of the "size" by dragging a strip of newspaper from one end to the other.

Hard water:If the water in your area is "hard" (contains lots of minerals) you will need to add some of our Water Softener. Hard water will interfere with the process.

Reusing the size

The size can be used over and over again. It can be kept for 3 to 4 days at room temperature before it begins to mold and must be discarded. To keep it longer, refrigerate. (Mark and tape the container clearly so it is not eaten.) Warm it to room temperature before using. If the "size" has been sitting awhile, clear the surface of tension and dust with strips of newspaper before using.

Preparing the fabric

Pre-wash the fabric with Synthrapol or regular fabric detergent and dry. This will wash out anything that is likely to prevent the paint from sticking.

Dissolve 3 TBS of Alum per quart of hot water. Cool to room temperature. Dip the fabric into the alum solution or if necessary, such as for paper, sponge it on very thoroughly. Lay it out flat to air dry, stretched if possible to avoid wrinkles. The fabric must be treated and must be dry before it is marbled. It is best to use the treated pieces within 24 hours. If you can't, then wash out the alum and try again another time. Careful! Too much Alum or too long of exposure weakens the fabric! Weakened fabric can shred when pulled on or even during sewing and washing, and sometimes doesn't become obvious until it has been washed more than once.

Caution - Ironing the fabric to remove wrinkles once the fabric has been treated is not recommended, as alum plus heat can weaken the fabric too. Small wrinkles will not effect the print.

Now Let's Get Started! Floating the paints

You may need to thin some paints before they will float. Use a few drops of Dispersant and a little water to thin them to the consistency of whole milk in a paper cup or one of the Color Mixing Cups.

With an eye dropper, lay the paint on the surface of the "size" as gently as possible. The drop should spread out to a circle 2-3” in size. As the paint spreads out on the surface some may sink to the bottom - it's ok as long as most of it stays on the surface. If too much seems to be sinking, thin the paint a bit more. If the drop spreads out too far, thicken the paint by adding a bit from the bottle. Keep adding paint to the surface until they seem intense or you are happy with the proportion of the colors.

The order in which you drop the paints directly affects the look of the finished piece. As you add new colors, the ones added previously will intensify as they are pushed together. You can add new colors next to, or on top of, the ones already there. Some paints will spread faster and push others out of the way more, you should keep notes if you want to repeat effects. The colors don't mix, but rather stay separate. You can remove the paint and start over by laying newspaper on the surface to pick up all the paint from the surface.

Pro-tip: Making a small side frame of size for testing your paint consistency can help you get clear how your paints will act before 'going for it'!

Making the designs

Anything goes when it comes to making your designs, in fact that's a main part of the fun. With all the desired colors of paint on the surface, use your rakes, combs or found items to carefully create swirls and design patterns.

Going back and forth with a toothpick or chopstick will produce chevron patterns.

Using a wide spaced comb or sort of rake in one-direction gives an interesting series of rounded, repeating shapes.

Using a skewer to make series of spirals will result in a "snail motif."

Dip a whisk or a bundle of broom straws in some paint and flick drops onto the surface.

Create "negative" areas in the design by placing soapy water on the surface with an eye dropper or by sprinkling it on. Use 1/8 teaspoon of liquid soap to 1/2 cup of water. Use this like a "clear paint" in your designs

Applying the paints to your fabric

Lay the middle of the fabric down first and let the ends roll out onto the surface so no air is trapped underneath. Leave the fabric down for 2-5 seconds before lifting it off. Try to "peel" the fabric off the surface so it doesn’t fold onto itself.

Dash to the sink or have a bucket handy and gently rinse with cold water to remove the alum and excess size. Now lay flat or hang to air dry. Don't wring or squeeze as the paint will not be 100% set until it has dried and been ironed.

Because there were two of us, we did it in washer woman fashion.  Each of grabbed the opposite end of the silk and one went down while the other up and washed very quickly for a few minutes.  You must get the Alum solution back out of the silk because it will deteriorate the silk. Hang to dry.

When the item is completely dry, heat set according to the heat setting instructions for the brand of paints you are using.

To set the paint into the silk, after the marbled silk is dry, place in the dryer for 2 hours.

If you are doing two-sided items like T-shirts, cut a piece of cardboard to size and cover with plastic or Saran wrap and insert into the shirt. Do one side, re-do the colors and then do the other side.

After each "printing" you can either add more paint or clear the surface with newspaper and start a new design.

Cleaning Up

Skim the surface of the marbling base with a strip of newspaper. If you're planning to reuse it soon, cover the paint mixture with plastic wrap or airtight lids. The size is usually good for more than one session.

Tear your strips, about 2 inches wide, before you begin.

Tear your strips, about 2 inches wide, before you begin.

If you’re not using your size again pour it down the toilet or run lots of hot water with it down the drain to avoid clogs.

When we finished, we had a small battery powered pump that we submerged in our carrageen solution after we had removed as much paint as we could from the solution and pumped the solution into a bucket to carry outside, if you live in an area where you do not want to put this down drains like me.  Then we washed the pump and cleaned the plastic with hot water.

Rinse the marbling tools in lukewarm water without soap. Soap residue on tools can contaminate future prints.

Rinse the tray thoroughly in a sink. Again, do not use soap.

Our dry marbled silks.

Troubleshooting

The marbling paints sink to the bottom of the tray.

• The size might be too thin or old. Add 1 teaspoon of Methocel (Methocelulose) powder per gallon of solution, or throw out and start a new recipe.

• Marbling colors are too thick. Add water to thin the colors, skim the marbling base, then test. You may need to add Synthrapol to the paints to improve its ability to spread and float.

The marbling colors spread too much or not at all.

• You might have added too much water or surfactant to the marbling color. Add more paint to balance it out.

• Size maybe too thick causing the drop to just sit on the surface. Add water to the size to thin it out. Skim, then re-apply marbling colors. Experiment with it to achieve the desired effect.

The marbled print appears fuzzy.

• The marbling base is too thick. Add water to the size, then re-apply paints.

• The marbling colors might be too thick. Thin the colors with water, then test.

• There was too much time spent between making the pattern and putting the fabric in the paint mixture. Work more quickly.

• The most frequent disaster is that the fabric falls apart at the end. It's from the Alum. Make sure you are not using more alum then recommended and use your fabric right away or wash it out.

• As you may have surmised by now, marbling can be a messy project, one which is best done with enough space to spread things out, and with lots of newspapers on hand. It's a great outdoor project when weather permits! However, the results are unique and spectacular!

Saturday Day 2

Making a Lamp

Purchase Directions from Karen Sistek, email her daughter:

Kim Sistek <silklampsbykaren@gmail.com>

The following are my adaptations to placing the silk onto the plastic styrene, which is the frame that the silk is adhered to to form the shade for the lamp.  I ordered the plastic styrene from The Lamp Shop, www.lampshop.com.  I cut it to size according to Karen's directions and then adhered it to the silk

Start by restretching you silk onto a frame of your choice.  Make sure the silk is stretched tautly without any puckers.  Make sure your table surface is clean and turn your stretcher with the silk upside down.

Hold the piece of cut styrene above the painting to find what part of the silk you want to adhere for the shade.  Make sure that you leave at least a 1/2 inch margin around the styrene of the marbled silk because you will wrap at least one side.

Start to unpeel the paper from the adhesive side of the styrene.

Press this side of the sticky styrene to the stretched silk and rub with your hand and then with the brayer, a tool on Karen's tool list for this project. I had the one you see.

Finish adhering the styrene to the stretched marbled silk and rub to smooth out with the brayer.

Take a piece of double sided sticky tape (see Karen's Instructions) and apply it to the outside edge of the styrene that with be part of the back seam for the lamp.

Remove the paper backing from the tape and carefully adhere the marbled silk off the styrene to the back side of the double sided tape.  Make sure there are no puckers in the silk.

Next is applying the tape and glue to form the seam for the back of the lamp shade.  I use the glue as well as the double sided tape because the tape does not always hold by itself.

Using a stove pipe (see Karen's instructions) size the lamp shade and apply the double sided tape and some Quick Glue  (also available from the Lamp Shop online) to marbled silk now with the styrene attached.

Slide the lamp shade off the stove pipe and put it on the frame of the lamp.

Voila!  A beautiful marbled lamp.

AirPen Pro and Resists Videos by Pamela Glose and Linda Marcille

by Kathy Goodson

For many of us silk painters, who find that as we are aging, squeezing an applicator is getting harder and harder, a wonderful tool called the AirPen Pro is available.  (I have one, but have not been able to use it yet.)  There are 2 videos I have found online by two fabulous silk painters: Pamela Glose and Linda Marcille.  I am including the videos here as they say it best.

 Pamela is using a water based resist and Linda Marcille is using Resistad, a New Zealand resist available from New Zealand ProColour or through Diane Tuckman's website here in the States.

Pamela Glose (top) Linda Marcille (bottom)

Introduction to Silk Painting at the NC Arboretum

by Kathy Goodson

Click on the picture to change

Click on the picture to change.

Another wonderful class of very talented creative students. (This time I remembered to take pictures.) Proud of their work, although I did not get pictures of their larger circle disks and some very imaginative designs.
